VARIABLE SPEED INDUCTION MOTOR

Working Range

The working range line shows the working limit (at the constant rating) for the variable speed motor. The permissible torque should fall within the shaded portion.

If you use the motor with the permissible torque exceeding the working range line (falling within the portion not shaded), the motor may be burned out due to a high temperature rise or the gear tooth may be damaged



Download For Specification

0 People watching this product now!
Deskripsi

Deskripsi



FEATURES

  • By using it together with a speed controller, you can vary the speed over a wider range (90 r/min to 1400 r/min for 50 Hz and 90 r/min to 1700 r/min for 60 Hz).
  • Various functions such as variable speed, braking, normal/reverse run and soft-start/soft-stop are
  • Feedback control with the built-in tacho-generator gives a constant speed despite of frequency change
  • The motor output is 3 W to 90 W
