AH1 (FJ) Switches
TYPICAL APPLICATIONS
• Electric pot
• Automobiles (Detection of key position), etc
| Test barang acs80 | 50kw ,60kw ,70kw |
|---|
0 People watching this product now!
Deskripsi
Deskripsi
Features
1.Compact size, light weight and high precision
2.Switches that can be used with M2 general-purpose screws
3.Integrally molded terminals that discourage inflow of solder flux provide and also switch body has stand-off
4.Lineup also includes AgNi alloy + Au-clad contact types optimized for low-voltage current loading
5.Self-standing terminal easily mounted on PC boards
6.Protection grade: IP40
Produk Terkait
KT4H / KT4B – space saving, high perfomance
- Multi-input Versatile thermocouple, RTD, DC voltage and DC current input for temperature detecting sensors
- Simple operation enables highly accurate temperature control All required operations can be enabled by the front keys and highly accurate PID control mode ensures an input span of ±0.2%.
- DIN Rail mounting types are aligned taking global market demand into consideration The KT7 series is equipped with DIN rail mounting complying to DIN standards. Furthermore, because its control panel is compact, the KT7 saves space.
- Nine step pattern control possible. For KT2 series, despite DIN 48 × 24 size, selection is possible of control with fixed set point and nine step pattern control.
- Meets market demands for costeffectiveness The KT series offers both economy and high performance.
- The KT series complies with UL, CSA standards and CE marking.
- Improved visibility and ease of operation More compact than before The KT4H/KT4B series features the largest PV digit size in the industry. Visibility is improved with an 11-segment display. Connectable to a PC, it offers a full range of control and communication functionsN
Download for specificationsMINAS LIQI servo drives (low cost)
MINAS LIQI series servo drives are ideal for applications that require an affordable technological upgrade to improve reliability and performance. Machines for simple food processing, packaging, printing, metal processing, even small linear robots are but a few example applications for which MINAS LIQI drives are cut out. In combination with Panasonic FP series PLCs, e.g. FP0R and FP-X0, they can be used to realize simple motion solutions. Use our banner freeware PANATERM to configure MINAS LIQI. Download For Specification
Download For Specification
PANASONIC FP7 Series
FP7 CPU
- Equipped with a large memory capacity (up to 220k program steps or up to 500k data words) and a high-speed processor (11ns/step)
- Local & remote connectivity The standard CPU boards with Ethernet interface offer connectivity without limits, from remote programming to monitoring and data logging to FTP server, MEWTOCOL (client/server), EtherNet/IP and Modbus TCP. Together with the Mini-USB and the RS232C port, it is possible to connect up to 272 devices. Supported services include FTP client/server (file exchange), HTTP Client (data exchange / services with a HTTP server / cloud), and sending e-mails with attachments. The integrated web server allows access to the variables of the system / program or diagnostic information using a predefined page or a user-defined page created with the graphical tool "Web Creator" based on HTML5 technology. HTML pages can be viewed from any Internet browser even from mobile devices (smartphones and tablets).
- Security & reliability Built-in program backup. Production can resume in the event of fault. Original program is immediately to hand.
- Traceability Operational and program editing events are logged. Automatic logs of program download and upload are useful, especially for program debugging.
- Maintenance Hour meter operation. The built-in clock/calendar function can be adjusted via Ethernet.
Download for user manual.
Panasonic HMI GT02 Series
GT02 series
The GT02 offers a host of innovative functions and is also pleasing to the eye. The brilliant 3.8'' graphical touch display is illuminated by a maintenance-free 3-color LED backlight which comes in 2 variations: green/orange/red and white/pink/red. The first SD memory card slot in the three-inch class allows for easy screen data transfer, data logging and storage. A variety of other needs from manufacturing sites were also covered, including the connector location for efficient wiring, improved environmental resistance rated IP67, and a newly designed bracket for more secure fastening. You can choose between 12 different models, which differ in:- communication interface (RS232C or RS422/RS485),
- housing (pure black or hairline silver),
- power supply (5V or 24V DC) and
- SD memory card slot (with or without).
Key features
- 3.8'' STN monochrome display
- Resolution: 240x96 dots
- Degree of protection: IP67
- Mini USB interface
- SD/SDHC memory card slot for cards up to 32GB, class10 max. (GT02MQ2/GQ2)
- Dimensions: 112x74x27mm
- Graph, recipe and flow display functions
- Through function for simultaneous debugging of the GT and PLC
- GT link function - up to 32 Panasonic HMIs can be connected to one PLC
- Multiple PLCs - up to 31 Panasonic PLCs can be connected to one HMI
- Data logging function
- Isolated power supply for enhanced reliability
GT02 Datasheet.pdfPanasonic KT9 PID Temperature Controller, 96 x 96mm, 1 Output Relay, 100 → 240 V ac Supply Voltage
Professional range of Digital Temperature Controllers to suit a wide variety of applications. Flush mount controller with membrane sheet keys. Dual LED display to determine the actual & reference values at a glance.
Panasonic KT series provide an energy efficient solution without compromising on performance. Optional free software available from Panasonic to allow parameters to be set from a computer, along with data logging / monitoring facilities. This Temperature Controller software can be accessed via link in the datasheet Download for specification
Download for specification
PANASONIC Motor Induction 1 Phase Series
Features :
DOWNLOAD PDF FOR SPECIFICATION
- It is fitted for continuous running in one direction.
- Continuous time rating.
- The motor with national specifications is of heatproof class 120 (E); the motor with specifications compliant with overseas standards is of heatproof 130 (B).
- Because it is a capacitor-type induction motor, it has a high power factor and runs with a low noise level.
DOWNLOAD PDF FOR SPECIFICATION
SERVO MOTOR MINAS A6 FAMILY
High-speed response, high-precision positioning for quick and accurate movement
Our proprietary algorithm in addition to upgraded CPU and other hardware realized further high-speed response. Furthermore, high-precision positioning is achieved by automatically eliminating micro vibrations and machine oscillation caused by the resonance. |
Easy and quick setting, shortening conventional settling time by approx. 64%*1.
Newly developed fit gain function substantially reduces adjustment time. Adaptive notch filter and various gains can be automatically set and adjusted. |
Realized 3.2 kHz frequency response to improve productivity.
Realizes 3.2 kHz frequency response. At 139% that of conventional models*1, it enables hjgh-speed operation and improves productivity. |
Download For Specification
TH13/TH23 Hour Meters
Features
1.High-performance compact synchronous motor
2.Compact and stylish
3.Flat terminals for easy wiring
To weld the #187 flat connection terminals (receptacles), please use a "YC-051" tool manufactured by J.S.T. Mfg. Co. Ltd.
Typical applications
- Machine tools, automated machines, control panels
- Forming machines, medical equipment, generators, compressors
- Water treatment facilities, presses
- Motors, etc.
Download For Specification
