Panasonic FP7 Series

PANASONIC FP7 Series

, , ,

FP7 CPU

  • Equipped with a large memory capacity (up to 220k program steps or up to 500k data words) and a high-speed processor (11ns/step)
  • Local & remote connectivity The standard CPU boards with Ethernet interface offer connectivity without limits, from remote programming to monitoring and data logging to FTP server, MEWTOCOL (client/server), EtherNet/IP  and Modbus TCP. Together with the Mini-USB and the RS232C port, it is possible to connect up to 272 devices. Supported services include FTP client/server (file exchange), HTTP Client (data exchange / services with a HTTP server / cloud), and sending e-mails with attachments. The integrated web server allows access to the variables of the system / program or diagnostic information using a predefined page or a user-defined page created with the graphical tool "Web Creator" based on HTML5 technology. HTML pages can be viewed from any Internet browser even from mobile devices (smartphones and tablets).
  • Security & reliability Built-in program backup. Production can resume in the event of fault. Original program is immediately to hand.
  • Traceability Operational and program editing events are logged. Automatic logs of program download and upload are useful, especially for program debugging.
  • Maintenance Hour meter operation. The built-in clock/calendar function can be adjusted via Ethernet.
Download for user manual.
Quick view

PANASONIC PLC FP-e: PLC for Panel ounting

FP-e

The new multi-talented PLC combines the performance of an FP0-C14C PLC with a 2-line x 5-character display for monitoring messages and machine data. The FP-e was specially developed for PLC applications in which a minimal display of information at the machine itself is sufficient for the operator, who in turn can select actions via keys on the front of the FP-e. Several product types are available, offering various combinations with real-time clock, thermocouples, and RS232C or RS485 interface.   Features:
  • 5-character, 2-line, 3-colour display Letters and numerical values can be displayed. Simple messages as well as timer/counter settings and elapsed values can also be displayed.
  • Matches FP0 intelligence (equivalent to FP0-C14C) Programming software and cables are common for all FP Series PLCs, therefore the FP-e can use programs created for other FP Series PLCs. FPWIN Pro and FPWIN GR offer a convenient configuration dialog for the screen display.
  • Built-in operation switch Displayed setting values can be changed. The operation switch can also be used to input data.
  • Panel mounted type The front of the unit is waterproof (in accordance with IP66 and IEC standards), and it can be used on equipment that requires washing, such as food processing machines. 70mm depth (front panel excluded).

Quick view

PANASONIC Powerful compact PLC: FPΣ

, , ,

FP-Σ

The FP-Sigma features the very latest control technology and a compact structural design. It is able to communicate with all major factory automation products. Of course you can program the FP-Sigma using our FPWIN Pro software (conforming to IEC 61131-3), and it is compatible with all Panasonic controllers. Other highlights:
  • Large program memory (32k commands)
  • Large data memory (32k words)
  • Efficient motion control functions - 50kHz fast counter input - 100kHz pulse output - convenient positioning commands
  • Fastest processing time, 0.32µs/basic command
  • Real-time clock
  • Compact design (W 30 x H 90 x D 60mm)
  • Top communication performance thanks to 3 possible serial interfaces on the CPU
  • MODBUS RTU Master/Slave standard in all CPUs
Download for user manual.
