GT02 series

The GT02 offers a host of innovative functions and is also pleasing to the eye. The brilliant 3.8'' graphical touch display is illuminated by a maintenance-free 3-color LED backlight which comes in 2 variations: green/orange/red and white/pink/red. The first SD memory card slot in the three-inch class allows for easy screen data transfer, data logging and storage. A variety of other needs from manufacturing sites were also covered, including the connector location for efficient wiring, improved environmental resistance rated IP67, and a newly designed bracket for more secure fastening. You can choose between 12 different models, which differ in:

• communication interface (RS232C or RS422/RS485),
• housing (pure black or hairline silver),
• power supply (5V or 24V DC) and
• SD memory card slot (with or without).

Key features

• 3.8'' STN monochrome display
• Resolution: 240x96 dots
• Degree of protection: IP67
• Mini USB interface
• SD/SDHC memory card slot for cards up to 32GB, class10 max. (GT02MQ2/GQ2)
• Dimensions: 112x74x27mm
• Graph, recipe and flow display functions
• Through function for simultaneous debugging of the GT and PLC
• GT link function - up to 32 Panasonic HMIs can be connected to one PLC
• Multiple PLCs - up to 31 Panasonic PLCs can be connected to one HMI
• Data logging function
• Isolated power supply for enhanced reliability
